Documents: A6X30074029

Datasheet

A6X30074029 | MSP S00 4.5-6.3A SCREW 24pcs | Siemens Electrical

CIRCUIT-BREAKER SZ S00, FOR MOTOR PROTECTION, CLASS 10, A-REL. 4.5...6.3A, N-REL. 82A SCREW CONNECTION, STANDARD SWITCHING CAPACITY MULTI-UNIT PACKING PACKAGE = 24 UNITS

Brand: Siemens ElectricalSKU: A6X30074029

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to A6X30074029

Jump to: Overview & Specifications Reviews

Overview Details for A6X30074029

Specifications

Item Number	A6X30074029
Brand	Siemens Electrical
Connection type	Screw connection
freeship	upsground
Greatest value of overload release adjustment range	6.3 ampere
Height	3.940 IN
Integrated auxiliary switch present	FALSE
Integrated undervoltage tripper present	FALSE
Length	3.750 IN
Lowest value of setting range for overload tripper	4.5 ampere
Manner of using	Toggle
max. rated operating voltage	690 volt
min. rated operating voltage	690 volt
Number of auxiliary contacts as opener	0
Number of auxiliary contacts as shutter	0
Pole number	3
Power loss per pole; current-dependent [PlIp]	2.4 watt
Protection type IP	IP20
Rated current [In] for the power loss specification	6 ampere
Rated operating power with AC-3; 230 V	2 kilowatt
Rated operating power with AC-3; 400 V	2 kilowatt
Rated permanent current Iu	6 ampere
rated service short-circuit breaking capacity Ics at 400 V; 50 Hz	10 ampere
Release system	magnetic
Sensitive to phase failure	TRUE
suitable for mounting onto standard rails	FALSE
Weight	0.41400 LB
Width	1.970 IN
