Documents: 3RT23262AP00
3RT23262AP00 | CONTACTOR RES S0 35A 230VAC 5NO/1NC SPRG | Siemens Electrical
CONT., AC-1, 26KW/400V, AC-1 40A, 1S+1OE, AC 230V 50HZ, 4-POLE, 4S, SIZE S0, SPRING-TYPE TERM.
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to 3RT23262AP00
Overview Details for 3RT23262AP00
Specifications
Item Number | 3RT23262AP00 |
Brand | Siemens Electrical |
Height | 5.160 IN |
Length | 4.410 IN |
Modular version | TRUE |
Number of auxiliary contacts as normally closed contact | 1 |
Number of auxiliary contacts as normally open contact | 1 |
Number of main contacts as normally open contact | 4 |
Rated control supply voltage Us at AC 50HZ | 230 V |
Rated operation current Ie at AC-1; 400 V | 40 A |
Rated operation current Ie at AC-3; 400 V | 15.5 A |
Rated operation current Ie at AC-4; 400 V | 15.5 A |
Rated operation power at AC-3; 400 V | 7.5 kW |
Rated operation power at AC-4; 400 V | 7.5 kW |
Type of electrical connection of main circuit | Spring clamp connection |
Voltage type for actuating | AC |
Weight | 1.07800 LB |
Width | 3 IN |
