Sensor: Duct/Immersion, 10K-T3, 4”
Documents and manuals
Overview
Details for STE-1423
Sensor: Duct/Immersion, 10K-T3, 4”
The KMC STE-1400 Series, Type III, 10,000 ohm thermistor temperature sensors are available in different housings for surface, duct, duct averaging, immersion, strap-on, and outside air applications.
The STE-1423 immersion sensor is encapsulated in a 4-inch long, 1/4-inch O.D., 304 stainless-steel probe. The probe protrudes from the bottom of the sensor housing, minimizing lead length error. The probe inserts into an HMO-4545 stainless-steel thermowell.
For optimal sensing, use HMO-4532 thermal compound in the thermowell for optimal heat transfer from the thermowell to the probe.
For a 6-inch immersion sensor, see the STE-1424.
The STE-1423 immersion sensor replaces the older STE-1421 used with a (threaded) HMO-4534 thermowell. When replacing an STE-1421 sensor with an STE-1423, also replace the thermowell with an HMO-4545.
The STE-1423 may also be used as a duct sensor (without a thermowell).
Specifications
- Brand
KMC Controls
- Sensor Type
Temperature
