BI-BOX-0 | 4 CHANNEL SWITCH INPUT MODULE | ACI
4 Channel Relay Input Module, Q-Controller
Documents and manuals
ACI BI-BOX-0 Documents
Overview
Details for BI-BOX-0
4 CHANNEL SWITCH INPUT MODULE
The BI-Box Model is used for reading out contacts such as conventional switches and push buttons. Each BI-Box module has 4x inputs with internal 24VDC power source which can drive the LED in Q-Switch. The BI-Box and other IO-Box modules connect and communicate via a RS-485 2- wire connection to the Q-Controller. The Q-Controller supports any combination of the IO Box, the BI-Box can be up to 31 modules, plus 4 onboard switch inputs in Q-Controller, allowing a total of 128 switch inputs via a single Q-Controller. All BI-Box configuration information is stored in Q-Controller, so replacement modules with the same address do not need to be configured. The BI-Box high density packaging, removable terminal block and DIN rail mounting saves time and panel space. The module snaps easily onto standard top hat (T) profile DIN rail.
Specifications
Item Number | BI-BOX-0 |
Brand | ACI |
