29370 | toggle padlocking device, removable adapter, ComPact NSX, OFF position only | Square D by Schneider Electric

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to 29370

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Square D 29370 Documents

Datasheet More Info

Overview

Details for 29370

toggle padlocking device, removable adapter, ComPact NSX, OFF position only

It is a removable toggle padlocking device for circuit breakers. This locking accessory is compatible with Compact NSXm, Compact NSX, PowerPact B and EasyPact CVS products. It can receive up to three padlocks with diameter of 5 to 8 mm and is used to lock Compact NSXm in OFF position only. Locking in the OFF position ensures isolation as per IEC 60947-2.

Specifications

range compatibility: ComPact (ComPact NSXm);ComPact (ComPact NSX100);ComPact (ComPact NSX160);ComPact (ComPact NSX250);ComPact (ComPact NSX400);ComPact (ComPact NSX630);EasyPact (EasyPact CVS100);EasyPact (EasyPact CVS160);EasyPact (EasyPact CVS250);PowerPact (PowerPact B);TeSys (TeSys GV4);TeSys (TeSys BV4);ComPact Compact NSX100 DC;ComPact Compact NSX160 DC;ComPact Compact NSX250 DC;ComPact (Compact NSF250);ComPact (Compact NSJ400);ComPact (Compact NSJ600);ComPact (Compact NSX500);ComPact (Compact NB400);ComPact (Compact NB600)
Product or Component Type: Padlocking device
device short name: locking for 1 to 3 padlocks
accessory / separate part type: Keylock accessories
Mounting Mode: Removable
keylock destination: Toggle
number of locks: 3
key locking position: In front
locking options description: Lock OFF only;1 to 3 padlocks;Removable
Category: 00924-GJL THERM-MAG AND MAG-GARD
Discount Schedule: DE2
GTIN: 3303430293705
Returnability: No
Country of origin: FR
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 0.39 in (1.000 cm)
Package 1 Width: 3.07 in (7.800 cm)
Package 1 Length: 3.58 in (9.100 cm)
Package 1 Weight: 1.48 oz (42.000 g)
Unit Type of Package 2: S03
Number of Units in Package 2: 40
Package 2 Height: 11.81 in (30.000 cm)
Package 2 Width: 11.81 in (30.000 cm)
Package 2 Length: 15.75 in (40.000 cm)
Package 2 Weight: 4.60 lb(US) (2.087 kg)
Unit Type of Package 3: P12
Number of Units in Package 3: 320
Package 3 Height: 19.69 in (50.000 cm)
Package 3 Width: 31.50 in (80.000 cm)
Package 3 Length: 47.24 in (120.000 cm)
Package 3 Weight: 63.26 lb(US) (28.696 kg)
Warranty: 18 months
