TBH2600A0FV0Z00 | 6" CPVC TBH Series Ball Valve, FLGD Ends, FPM Seals, Z BALL | Hayward

Brand: HaywardSKU: TBH2600A0FV0Z00

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to TBH2600A0FV0Z00

Jump to: Overview & Specifications Reviews

Overview Details for TBH2600A0FV0Z00

6" CPVC TBH Series Ball Valve, FLGD Ends, FPM Seals, Z BALL

The TBH-Z Series (Z-Ball) true union ball valves have a drilled ball to vent gases for sodium hypochlorite service. Available in PVC or CPVC materials with FPM O-rings only and PTFE seats. Sizes ½”/DN15 to 6” DN150. All valves are assembled with silicone free lubricant. Assisting users in protecting property and life, a standard integral lock-out feature secures onto the body of the valve. Actuator ready design with ISO 5211 pattern – on all sizes. Fully pressure rated for 250 PSI / PN16 at 70°F/23°C non-shock up to 2”/DN50; sizes 2-1/2” / DN65 – 4” / DN100 are pressure rated for 235psi/PN16 at 70°F non-shock. The TBH-Z is available with IPS, DIN/EN or JIS socket, threaded and flanged end connections for global use. “Patented” & Other Patents Pending” Pat. No.: 11,131,404.

• Integral ISO 5211 Mounting Pad for Easy Actuation
• Standard Lock-Out Plate, Lock-Out / Tag-Out for up to 4 Locks
• Permanent Laser Markings, Eliminates Labels
• System friendly "Molded-In" Footpad for Skid or Panel Mount
• UV Resistant Sure Grip Ergonomic Handle
• FPM or EPDM Seals
• Double O-Ring Stem Seals
• Reversible PTFE Seats - Standard
• Easy Replacement for Existing Hayward TB-Z Series

Specifications

Item Number	TBH2600A0FV0Z00
Brand	Hayward
Body Material	CPVC
Category	N/A
Category	True Union Ball Valves
Chassis Description	Large Diameter Body
Class	N/A
Cv Coefficient	550
Cv Coefficient	550.0000
End Connection Material	CPVC
End Connection Type	Flanged
End Connection	Flanged
Flow Configuration	Bi-directional
Handle Material	GFPP
Material	CPVC
O-Ring Material	FPM
Operating Pressure [Max]	10 bar 150 psi
Operation Type	Manual
Pipe Size	6 in
Pressure Rating	150 PSI
Sealing Material	FPM
Seat Material	PTFE
Series	TBH Series With Z Ball True Union Ball Valves
Series	TBH-Z
Size	6"
Sub Category	N/A
SubCategory	TBH-Z Series "Z-Ball"
Subtype	Ball Valves
Subtype	Industrial Ball Valves
Type	Thermoplastic Valves
Valve Material	CPVC
Valve Type	Ball
