TBH2250A0SV0000 | 2-1/2" CPVC TBH Series Ball Valve, SOC Ends, FPM Seals | Hayward

Hayward | TBH2250A0SV0000
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to TBH2250A0SV0000

Documents and manuals

Hayward TBH2250A0SV0000 Documents

Overview

Details for TBH2250A0SV0000

2-1/2" CPVC TBH Series Ball Valve, SOC Ends, FPM Seals

The TBH Series features a low maintenance design with its new patent pending System2™ Sealing Technology for sizes up to 2”/DN50. Sizes 2-1/2” through 6” feature have energized PTFE seats with backing O-ring as standard. All seats are reversible to allow easy field rebuild. Assisting users in protecting property and life, a standard integral lock-out feature secures onto the body of the valve. Actuator ready design with ISO 5211 pattern – on all sizes. Available in sizes 1/4˝ through 6” / DN15 – DN150 in PVC and CPVC materials. The TBH Series are fully pressure rated for 250 PSI / PN16 at 70°F/23°C non-shock up to 2”/DN50. Sizes 2-1/2”/DN65 – 4”/DN100 sizes are pressure rated for 235psi at 70°F non-shock. Lastly, the TBH is available with IPS or DIN/EN and JIS socket, threaded and flanged end connections for global use. “Patented” & Other Patents Pending” Pat. No.: 11,131,404.

• Full 250 psi / PN16 Rating up to 2”/DN50 and 235psi/PN16, Non-Shock at 70°F / 23°C.
• Integral ISO 5211 Mounting Pad for Easy Actuation
• Standard Lock-Out Plate, Lock-Out / Tag-Out for up to 4 Locks
• System2™ Sealing Technology Seat Carrier Design for sizes up to 2”/DN50– Patent Pending
• Permanent Laser Markings, Eliminates Labels
• System friendly "Molded-In" Footpad for Skid or Panel Mount
• UV Resistant Sure Grip Ergonomic Handle
• FPM or EPDM Seals
• Double O-Ring Stem Seals
• Reversible PTFE Seats - Standard
• Easy Replacement for Existing Hayward TB Series

Specifications

Item Number TBH2250A0SV0000
Brand Hayward
Category N/A
Category True Union Ball Valves
Chassis Description Large Diameter Body
Class N/A
Cv Coefficient 340
Cv Coefficient 340.0000
End Connection Type Socket
End Connection Socket
Flow Configuration Bi-directional
Handle Material GFPP
Material CPVC
O-Ring Material FPM
Operating Pressure [Max] 16 bar 235 psi
Operation Type Manual
Pipe Size 2-1/2 in
Pressure Rating 235 PSI
Sealing Material FPM
Seat Material PTFE
Series TBH
Series TBH Series True Union Ball Valves
Size 2-1/2"
Sub Category N/A
SubCategory TBH Series Ball Valves
Subtype Ball Valves
Subtype Industrial Ball Valves
Type Thermoplastic Valves
Valve Material CPVC
Valve Type Ball
