PWC1 | Power converter | plug-in | 115 VAC | 24 VDC | unregulated. | Dwyer
Power converter, plug-in, 115 VAC, 24 VDC, unregulated.
Documents and manuals
Dwyer PWC1 Documents
Overview
Details for PWC1
Power converter | plug-in | 115 VAC | 24 VDC | unregulated.
Series FPCA Flow Power/Controls Accessories
The Series FPCA Flow Power Control Accessories include mounting kits, powerconverters, and power supplies for compatible flow meters. These accessories simplifyinstallation by offering meter and wall mounting options. Furthermore, power input andsupply are no longer an issue with the power converter and dual power supply. The WMKcan be used to mount Series BAT, RTI, or PWD on Series PDWS. The MMK can be usedto mount either Series BAT or RTI to a wall with the use of Series EFS2, IEFS, PDWS,IPFS, TBS, or FLMG. Model PWC1 can be used with Series PDW, EFS2, or IEFS toconvert 115 VAC to 25 VDC. Model PWC2 can be used with Series EFS2, IEFS, PDWS,IPFS, and TBS to convert 115 VAC to 12/24 VDC and provide dual power output for usewith Series BAT and RTI.
Specifications
- Series
- FPCA Flow Power/Controls Accessories
- Category/Type
- Flow
- Type
- Flow Transmitters
- Series
- FPCA Flow Power/Controls Accessories
- PWC1/PWC2
- Temperature Limits
- 32 to 140°F (0 to 60°C).
- Output
- 24 VDC @ 500 mA.
- Power Requirements
- 120 VAC; 60 Hz; 19 W.
- Electrical Connection
- 22-18 AWG screw terminal.
- Weight
- Contact factory.
- WMK/MMK
- Temperature Limits
- -22 to 148°F (-30 to 65°C).
- Enclosure Material
- Powder-coated diecast aluminum.
- Weight
- WMK: 1.25 lb (567 g); MMK: 1.75 lb (794 g).
