A-700-4 | Power supply ( 4.8 A). | Dwyer
Power supply ( 4.8 A).
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to A-700-4
Documents and manuals
Dwyer A-700-4 Documents
Overview
Details for A-700-4
See catalog product page for full listing
Power supply ( 4.8 A).
MODEL A-700 POWER SUPPLY
Economical, Compact
The economical and reliable SERIES A-700 power supply is suitable for powering all Dwyer pressure, temperature or air velocity transmitters. Inexpensive, open-frame design allows convenient access to input/output solder terminals. Auxiliary inputs are selectable for operation from power sources found worldwide. Compact size eases enclosure installations.
Product Applications
- BAS
- HVAC
- Universal supply voltage input
- Compact size
Specifications
Item Number | A-700-4 |
Brand | Dwyer |
AC Input | 100/120/220/230-240 VAC ±10%; 47-63 Hz. |
Ambient Operating Temperature | 32 to 122°F (0 to 50°C). |
Category/Type | Miscellaneous |
DC Output | 24-29 VDC regulated. |
External Fuse Required | 0.5 Amp for 100-120 VAC; 0.25 Amp for 220-240 VAC. |
Maximum Current Output | A-700: 0.5 A @ 60 Hz; 0.45 A @ 50 Hz; A-700-2: 2 A @ 60 Hz; 1.8 A @ 50 Hz; A-700-3: 4.8 A @ 60 Hz; 4.5 A @ 50 Hz. |
Type | Power Supplies & Transformers |
Weight | 2 lb. |
