179359LF | Be9025T, e-90 Series, In-Line Centrifugal Pump, 1-1/2 HP, 208-230/460 Volts, 3 Phase, 3450 RPM, 1.25AAB Size, 3.875" Impeller, Bronze Volute | Bell & Gossett

Be9025T, e-90 Series, In-Line Centrifugal Pump, 1-1/2 HP, 208-230/460 Volts, 3 Phase, 3450 RPM, 1.25AAB Size, 3.875" Impeller, Bronze Volute

Description

The 179359LF from the e-90 series is an in-line centrifugal pump that offers a wide hydraulic coverage in heating and cooling applications. Pumps from this series can withstand temperatures ranging from -10 to 250 degrees Fahrenheit.

You can mount e-90 series close-coupled in-line pumps either vertically or horizontally, with connection sizes ranging from 1 x 1 inch to 3 x 3 inches. The 179359LF model suits most small commercial HVAC systems. The 175 PSI (pounds per square inch) rating makes this pump an excellent choice for chilled and boiling water loops, pressure boosting, heat and refrigeration exchanger circulation.

Features and Benefits

• Flexible design. The e-90 pumps are designed based on the NEMA 56J motor. Thanks to close-coupled platforms, they also don’t require a couple, bearing frame, shaft sleeve, or stub-shaft to mount.
• Straightforward setup. The compact and versatile design allows you to install the pipe with a minimal amount of effort. All e-90 series devices mount to the piping systems vertically and horizontally.
• Variety of sizes. The pumps in the e-90 series will most likely fit all your needs. Optionally, this model comes as a header pump that installs directly to the boilers. Overall, you can pick from over 110 pre-configured designs for your piping system.
• Strong hydraulics. All pumps in the e-90 series (including 179359LF) provide excellent hydraulic efficiency. You can expect up to 18% improvements at BEP.
• High durability. The e-90 series in-line pump motors have a 56J NEMA standard (ODP with drip cover), which guarantees long service life. Furthermore, the robust mechanical seal with 303 stainless steel shaft provides great corrosion resistance and thermal capacity, significantly decreasing the need for maintenance and repairs.
• Low maintenance. The durable construction and excellent design reduce the need for maintenance. Moreover, the one-piece unitized mechanical seal and back-pull-out design allow repairing the pump without disturbing the piping.
• Space savings. The pump is relatively compact and offers two mounting options. Therefore, it allows you to save a lot of free space.
• Energy efficiency. Optimized motors improve hydraulic performance while optimizing energy consumption so that you can spend less money on electric bills.

Applications

• Chilled and boiling water loops
• Portable hot water
• Heat and refrigeration exchanger circulation
• Pressure boosting

Bell & Gossett e-90 Close Coupled In-Line Centrifugal Pump

The e-90 pump is a versatile in-line pump that offers wide hydraulic coverage well suited for the small commercial HVAC market. Ths pump is designed to be mounted in the piping and can be installed either horizontally or vertically.

Features

• Long life and robust performance
• Robust EPR/carbon/silicon-carbide mechanical seal lowers maintenance and increases the life of the pump
• Energy savings
• Increased hydraulic efficiency
• Space savings and installation flexibility close-coupled
• Ability to mount horizontally and vertically
• Back-pull-out design allows the pump to be serviced without disturbing the piping
• NEMA standard motor 56J in ODP enclosure with vertical drip covers
• Excellent for boiler recirculation applications

Applications

• Hydronic heating and cooling
• Pressure boosting
• Refrigeration and heat exchanger circulation
