QAM2171.040 | Duct Temperature Sensor, 4 to 20 mA, 16-Inch | Siemens

Duct temperature sensor with a 4 to 20 mA output in a plastic housing. This unit has a 16-Inch (40 cm) probe.

Siemens | QAM2171.040
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to QAM2171.040
Jump to: DocumentsOverview SpecificationsReviews

Documents and manuals

Siemens QAM2171.040 Documents

Datasheet(Duct temperature sensors QAM2161.040. QAM2171.040. with 0…5 V output)Datasheet(Duct Temperature Sensors Technical Specification Sheet)Datasheet(Duct temperature sensors QAM2161.040. QAM2171.040. w/o 0…5 V output)Declaration of conformity(EU Declaration of Conformity QAM21xx)Declaration of conformity(RCM Supplier's declaration QAM21... / QFM...)Declaration of conformity(KC Certificate QAM2171.040)Declaration of conformity(UK Declaration of conformity for QAM2161.040. QAM2171.040)Declaration of conformity(Test report MTBF for QA..)Environmental Declaration(Duct Temperature Sensors. Immersion Temp.Sensors. Outside Temp.Sensors)Installation instruction(Duct Temperature Sensor Installation Instructions)Mounting instruction(Immersion and Duct temperature sensor QAE... QAM... with 0…5 V output)Mounting instruction(Immersion and Duct temperature sensor QAE... QAM... w/o 0…5 V output) Installation Instructions More Info

Overview

Details for QAM2171.040

Duct Temperature Sensor, 4 to 20 mA, 16-Inch

Duct temperature sensor with a 4 to 20 mA output in a plastic housing. This unit has a 16-Inch (40 cm) probe.

Specifications

Immersion length
400 mm
Measuring range, temperature
-50…50 °C
Power consumption
1 VA
Signal output temperature
DC 4...20 mA
Operating voltage
13.5…35 VDC
Measurement accuracy
At -50…50 °C: ±0.9 K
Time constant
Air v=2 m/s: 30 s
Probe length
400 mm
