GVD121.1U | Damper Actuator | Spring Return | 24 VAC | On/Off | 200 lb-in | Siemens

Fire and Smoke Damper Actuator 200 lb-in 2-position control , Spring Return, 24 VAC compatible with built in Electronic Fuse Link capability. For use on UL-listed smoke control dampers and combination fire/smoke rated dampers. Designed to meet UL555S.

Brand: SiemensSKU: GVD121.1U

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to GVD121.1U

Suggested Alternatives

Belimo EFB24 Damper Actuator | 270 in-lb | Spg Rtn | 24V | On/Off | Blackhawk Supply

Brand: Belimo

SKU: EFB24

$625.05

Jump to: Overview & Specifications Reviews

Overview Details for GVD121.1U

Damper Actuator | Spring Return | 24 VAC | On/Off | 200 lb-in

Fire and Smoke Damper Actuator 200 lb-in 2-position control , Spring Return, 24VAC/DC compatible with built in Electronic Fuse Link capability. For use on UL-listed smoke control dampers and combination fire/smoke rated dampers. Designed to meet UL555S.

Specifications

Actuator Type: Electronic Fire and Smoke
Actuation Style: Rotary
Control or Fire/Smoke Type: Fire/Smoke Control Damper
Electronic Fusible Link (EFL): YES
Plenum or Standard Rating: Standard
Torque: 200 lb-in
Fail Safe: Yes
Spring return function: Spring return function
Control Signal: 2-position
Positioning time: Run time for 90° 30s nominal, Spring return 15 s max
Power consumption: 35 VA / 9 VA, Run / Hold
Ambient temperature, operation: 0…140 ºF
Ambient humidity, operation: 95 % r.h.
Angular rotation: 95°
Supply Voltage: 24 VAC
Frequency: 50/60
Auxiliary switch: 0
Cable length: 3 ft
Dimensions (W x H x D): 3.8 x 10.75 x 3.4 in
Material, housing: NEMA 1 / IP40, plenum-rated plastic, high temperature polymer
Standard: UL60730; cUL CSA 60730; CE conformity for Residential, Commercial, and Industrial environments
