GSD161.1P | Damper Actuator | Non-Spring Return | 24 VAC/DC | 0-10Vdc / 2-10Vdc | 20 lb-in | Siemens
Damper Actuator 20 lb-in 0(2) to 10 modulating control signal, non-spring return plenum rated for low torque VAV applications and small dampers.
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to GSD161.1P
Documents and manuals
Siemens GSD161.1P Documents
Datasheet(OpenAir GSD Series Non-Spring Return. 20 lb-in (2 Nm). Rotary Electronic Damper Actuators Technical Instructions)Datasheet(OpenAir GSD Series. Non-Spring Return. 20 lb-in (2 Nm). Rotary Electronic Damper Actuators Submittal Sheet)Installation instruction(OpenAir GSD Series. Non-Spring Return Rotary Electronic Damper Actuators Installation Instructions) Installation Instructions More Info
Overview
Details for GSD161.1P
Damper Actuator | Non-Spring Return | 24 VAC/DC | 0-10Vdc / 2-10Vdc | 20 lb-in
Damper Actuator 20 lb-in 0(2) to 10 modulating control signal, non-spring return plenum rated for low torque VAV applications and small dampers.Specifications
- Actuator Type
- Non-spring return
- Actuation Style
- Rotary
- Control or Fire/Smoke Type
- Control Damper
- Plenum or Standard Rating
- Plenum
- Torque
- 20 lb-in
- Fail Safe
- No
- Control Signal
- 0...10Vdc / 2...10Vdc
- Positioning time
- Runtime for 90° 30 s
- Position feedback
- Yes
- Power consumption
- Running: 2.4 VA (1.4 W), Holding: 1.2 VA (0.7 W)
- Ambient temperature, operation
- -25 to 130 °F, -32 to 55 °C
- Operating voltage
- 24 VAC, 24 VDC
- Supply Voltage
- 24 VAC/DC
- Frequency
- 50/60 Hz
- Auxiliary Switch
- No
- Cable length
- 3 ft
- Dimensions (W x H x D)
- 2.83 x 5.86 x 2.45 in
- Material, housing
- IP54 enclosure, Plenum rated rugged plastic
