HU362DSWC | Safety switch, heavy duty, non fusible, 60A, 600 VAC/VDC, 3 poles, 60 hp, NEMA Type 4, 4X, 5, 304 steel, crouse hinds | Square D by Schneider Electric

Brand: Square DSKU: HU362DSWC

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for HU362DSWC

Safety switch, heavy duty, non fusible, 60A, 600 VAC/VDC, 3 poles, 60 hp, NEMA Type 4, 4X, 5, 304 steel, crouse hinds

Product: Receptacle Switch
For Use With: Plug APJ6485 Crouse-Hinds Arktite
Disconnect Type: Non-fusible disconnect switch
Phase: 3 phase
Number of Poles: 3
Current rating: 60 A
Voltage Rating: 600 V AC;250 V DC
Enclosure Rating NEMA 3R: NEMA 4/4X/5 stainless steel 304
Maximum Horse Power Rating: 50 hp at 480 V AC 50-60 Hz for 3 phase motors;60 hp at 600 V AC 50-60 Hz for 3 phase motors;10 hp at 250 V DC
Mounting Type: Surface
Electrical Connection: Receptacle
Wire Configuration: 4-wire
Wire Size: AWG 12...AWG 2 aluminium;AWG 14...AWG 2 copper
tightening torque: 45 lbf.in (5.08 N.m) (AWG 6...AWG 4);40 lbf.in (4.52 N.m) (AWG 8);35 lbf.in (3.95 N.m) (AWG 14...AWG 10)
Depth: 5.11 in (129.79 mm)
Width: 10.79 in (274.07 mm)
Height: 16.87 in (428.50 mm)
Certifications: UL Listed
Category: 00118-H&HU SW;W/C-HINDS RECPT-WC
Discount Schedule: DE1
GTIN: 785901077954
Returnability: No
Country of origin: US
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 18.69 in (47.464 cm)
Package 1 Width: 7.37 in (18.732 cm)
Package 1 Length: 11.00 in (27.94 cm)
Package 1 Weight: 24.00 lb(US) (10.886 kg)
Warranty: 18 months
