YORK P/N 025-39110-003; 20 NM SPR RTN ACTUATOR PROP CTR 24 VAC MOLEX

The M9208-GGx-x Series Proportional Electric Spring Return Actuators are direct-mount actuators that operate on AC/DC 24 V power. These bidirectional actuators do not require a damper linkage, and are easily installed on round shafts from 5/16 to 5/8 in. (8 to 16 mm) or square shafts from 1/4 to 1/2 in. (6 to 12 mm) using the standard shaft clamp included with the actuator. An optional M9208-600 Large Coupler Kit is available for round shafts from 1/2 to 3/4 in. (12 to 19 mm) or square shafts from 3/8 to 9/16 in. (10 to 14 mm).

• Damper Actuator
• 24 VAC/VDC
• Proportional [0(2) to 10 VDC]
• Spring Return
• 177 in-lb Torque
• 48 in. Appliance Cable
• 150 sec Runtime
• NEMA 2
• Molex
