UZC-6 | UZC-6 Zone/Cntrl Pnl 2Stclg/3Stg Ht | EWC Controls
Documents and manuals
EWC Controls UZC-6 Documents
Overview
Details for UZC-6
UZC-6 Zone/Cntrl Pnl 2Stclg/3Stg Ht
Specifications
INPUT VOLTAGE: 19-30VAC 60 Hz Transformer 40-60VA MAX. NEC Class 2.
CURRENT DRAW: Max 14VA @ 24VAC.
OVER-CURRENT PROTECTION: 2.5 amp or 60 VA.
WIRING: 18 gauge Solid copper wire. Do not use Stranded or Shielded Cable.
TEMPERATURE: -20° to 160°F (-29° to 71°C).
HUMIDITY: 0% - 95% RH Non-Condensing.
Features
NUMBER OF ZONES:
2 - 3 Zones, Non-expandable.
COMPATIBLE EQUIPMENT:
Gas/Electric/Hydro – Up to 2 Stages Heating and 1 Stage Cooling.
Heat Pump Conventional – Up to 2 Stages Heating and 1 Stage Cooling.
COMPATIBLE THERMOSTATS:
Any single stage Heat/Cool Thermostat or 2 Stage Heat, 1 Stage cool Heat Pump Thermostat.
COMPATIBLE DAMPERS:
EWC Models URD, ND, RSD and SID. Any 24vac 3 Wire or 2 Wire damper.
ACCESSORIES:
Model SAS – Supply air sensor (Included)
Model CPLS – Coil Protection Lockout Switch.
ADDITIONAL FEATURES:
*Staging via Adjustable On-board Timer (7 to 42 Minutes).
*Enhanced Hydro-Air capabilities, can delay fan activation on Heating demand.
*Supply Air Temperature Monitoring to help protect HVAC equipment.
*Adjustable Purge time (90 or 120 seconds).
*On Board LED’s indicate system operation.
Specifications
Item Number | UZC-6 |
Brand | EWC Controls |
Type | Zoning Panel |
