HCHP-1K | Hydraulic hand pump | range 10 | 000 psi | with hose kit. | Dwyer

Hydraulic hand pump, range 10, 000 psi, with hose kit.

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to HCHP-1K

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Dwyer HCHP-1K Documents

Service Manual Series HCHP Catalog Page More Info

Overview

Details for HCHP-1K

See catalog product page for full listing

Hydraulic hand pump | range 10 | 000 psi | with hose kit.

SERIES HCHP HYDRAULIC CALIBRATION HAND PUMP

Patented Triple Filtration, Generates Pressure up to 10,000 psi (700 bar)

The Series HCHP Hydraulic Calibration Hand Pump utilizes a fully adjustable stroke control that allows for quick priming, easy pumping and fast pressure generation up to 10000 psi (700 bar). The ergonomically engineered handles provide extra comfort, while the triple filtration system ensures pump operation in spite of dirty conditions. The shatterproof reservoir and stainless steel construction guarantee leak free operation. The Series HCHP has oversized check valves to provide smooth controlled operation.

Specifications

Series: HCHP HYDRAULIC CALIBRATION HAND PUMP
Category/Type: Test Equipment
Type: Calibration Pumps
Series: HCHP HYDRAULIC CALIBRATION HAND PUMP
Output Ranges: 0 to 10000 psi (0 to 700 bar).
Process Connection: 1/4" NPT/BSP.
Gage Connection: 1/4" NPT/BSP.
Materials: SS; polyurethane; anodized hard-coat aluminum; PTFE; and nitrile.
Weight: 3 lb (1.36 kg).
