B232+AFRX24-MFT N4 | CCV | 1.25" | 2 Way | 37 Cv | Spg Rtn | 24V | MFT | NEMA 4 | Belimo

Characterized Control Valve (CCV), 1 1/4", 2-way, Cv 37 |Valve Actuator, Spring return, AC/DC 24 V, MFT/programmable, NEMA 4X

Belimo | B232+AFRX24-MFT N4
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to B232+AFRX24-MFT N4

Documents and manuals

Belimo B232+AFRX24-MFT N4 Documents

Overview

Details for B232+AFRX24-MFT N4

CCV | 1.25" | 2 Way | 37 Cv | Spg Rtn | 24V | MFT | NEMA 4

Specifications

Valve specifications
Angle of Rotation
90
Controllable Flow Range
75B0
Cv
37
End Fitting
Internal thread
Fluid
Chilled or hot water up to 60% glycol
Pattern
2-way
Pressure Independent
NO
Trim
Stainless steel
Valve Size
1.25" [32]
Actuator specifications
Actuator Type
Spring return
Control Type
MFT/Programmable
Degree of Protection
IP66 NEMA 4X UL Enclosure Type 4X
Electrical Connection
cable
Manual Override
5 mm hex crank (3/16" Allen) supplied
Power Consumption (Holding)
3 W
Power Consumption (Running)
7.5 W
Running Time (Fail-safe)
<20 s
Running Time (Motor)
150 s / 90B0
Voltage AC/DC
AC/DC 24 V
