B210+TR24-3 US | CCV | 0.5
Get Special Pricing!
Log In or Create an Account for the LOWEST PRICING on our most Popular Brands!
Brand: BelimoSKU: B210+TR24-3 US

Web Price:

$147.60
Availability: This product is currently available to purchase
This item ships FREE*
Shipping and Returns Terms

Speak With a Technical Expert

Call (847) 773-0645

Hours: 9am - 5pm CDT M-F

B210+TR24-3 US | CCV | 0.5" | 2 Way | 1.2 Cv | w/ Non-Spg | 24V | Floating | Belimo

Belimo | B210+TR24-3 US
The photo is for representation purposes only and may not be a photo of product being purchased.
5 The right water and steam regulation valve
This Cast Iron Globe Valve has been good to me. Even though it handles hot loads of steam and water, it never broke down or has had a single leak. Since there are no leaks, I managed to conserve energy saving me up on the bills. The cast iron make of the product can withstand the immense pressure even when shutting off. I have heard no complaints from my occupants since the product's installation and if it makes them happy, heck I'm happy too.
5 Really innovative
An innovative Belimo steel ball and stem valve with an actuator that is compatible with most of the innovative heating and cooling systems. Once you place it in your system there is no other need for maintenance. There is the chance for a manual override simply by pressing down the handle. No need for a dedicated power supply makes it easier to connect it to your systems electrical network. The ambient temperature can come up to 50C that is among the highest in its class.
5 The best among valves
Another simple valve coming by Belimo that has become the world leader in non-spring, floating valves. It shows an angle of rotation of up to 90 degrees while giving you the time to regulate the pressure of your heating system. The device has a lower IP40 waterproof ability and the motor running time has been close to 90 seconds that is among the longest in the heating market. The operation noise keeps on being bearable. This device is lightweight and complies with the ISO 9001 obligations.

Overview

Details for B210+TR24-3 US

CCV | 0.5" | 2 Way | 1.2 Cv | w/ Non-Spg | 24V | Floating

Application

This valve is typically used in air handling units on heating or cooling coils, and fan coil unit heating or cooling coils. Some other common applications include Unit Ventilators, VAV box re-heat coils and bypass loops. This valve is suitable for use in a hydronic system with variable flow.


Specifications

Item Number
B210+TR24-3 US
Brand
Belimo
Control Input
Floating
Control Valves Type
CCV
Cv / GPM
1.2 Cv
Spring Return
Non-Spring Return
Valve Size
0.5" - 2 Way
Voltage
24V
Actuator specifications
Actuator Type
Non fail-safe
Control Type
Floating/3-point
Degree of Protection
IP40 NEMA 1
Electrical Connection
cable
Manual Override
Push down handle
Power Consumption (Running)
1 W
Running Time (Motor)
90 s / 90B0
Voltage AC/DC
AC 24 V
Valve specifications
Angle of Rotation
90
Controllable Flow Range
75B0
Cv
1.2
End Fitting
Internal thread
Fluid
Chilled or hot water up to 60% glycol
Pattern
2-way
Pressure Independent
NO
Trim
Stainless steel
Valve Size
0.5" [15]

Documents and manuals

Belimo B210+TR24-3 US Documents

Reviews

Customer Reviews
5.0 Based on 3 Reviews
5 ★
100%
3
4 ★
0%
0
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Write a Review

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

Filter Reviews:
ZG
03/10/2020
Zaine G.

The right water and steam regulation valve

This Cast Iron Globe Valve has been good to me. Even though it handles hot loads of steam and water, it never broke down or has had a single leak. Since there are no leaks, I managed to conserve energy saving me up on the bills. The cast iron make of the product can withstand the immense pressure even when shutting off. I have heard no complaints from my occupants since the product's installation and if it makes them happy, heck I'm happy too.

SS
01/06/2020
Stefan S.

Really innovative

An innovative Belimo steel ball and stem valve with an actuator that is compatible with most of the innovative heating and cooling systems. Once you place it in your system there is no other need for maintenance. There is the chance for a manual override simply by pressing down the handle. No need for a dedicated power supply makes it easier to connect it to your systems electrical network. The ambient temperature can come up to 50C that is among the highest in its class.

ER
11/23/2019
Erin R.

The best among valves

Another simple valve coming by Belimo that has become the world leader in non-spring, floating valves. It shows an angle of rotation of up to 90 degrees while giving you the time to regulate the pressure of your heating system. The device has a lower IP40 waterproof ability and the motor running time has been close to 90 seconds that is among the longest in the heating market. The operation noise keeps on being bearable. This device is lightweight and complies with the ISO 9001 obligations.
