KW320B-P1-D-IP-RC | Power Meter, Bi-Directional, 3 Circuit, Ethernet, BACnet IP, Rogowski Coil Inputs, LCD Display, No I/O Options | ACI (OBSOLETE)
Power Meter, Bi-Directional, 3 Circuit, ANSI 0.2 Class Accuracy, Ethernet Communication, BACnet IP Only, Rogowski Coil Inputs, LCD Display, No I/O Options
Overview
Details for KW320B-P1-D-IP-RC
Power Meter, Bi-Directional, 3 Circuit, Ethernet, BACnet IP, Rogowski Coil Inputs, LCD Display, No I/O Options
The KW320B meter combines high performance with ease of integration via BACnet-IP (BTL Listed) to provide a power and energy monitoring solution. Over 100 metering parameters can be monitored in real-time from a built-in web interface and encryption ensures that communication is secure. The mobile-friendly web interface allows users to remotely monitor and configure meter on mobile devices. KW320B meters support all electrical system configurations from single phase to three phase and their tamper-proof design is approved for revenue applications (ANSI C12.20 Class 0.2 and IEC 62053-22 0.2s). The meter comes standard to be mounted in a 4 Round or an IEC 92mm DIN Square form or has the flexibility to be mounted to 35mm DIN rail with the AXM-DIN adapter (See Accessories Ordering). This product provides demand measurement of Current, Active Power, Reactive Power and Apparent Power “ see data sheet for all parameters monitored and metered. Current input options are compatible with any ACI 333mV or Flexible Rogowski Coil CT. Meters come standard with a three channel CT input to accurately measure neutral current. CTs are sold separately as shown on the ACI Split-Core, Solid-Core and Rogowski Current Transformer product data sheets.
Specifications
Item Number | KW320B-P1-D-IP-RC |
Brand | ACI |
