TAHM0 | Temp | Duct Avg. | 12 Ft | 20k NTC | Veris
Copper Tubing 12 ft 20 kOhm Thermistor NTC Averaging Temperature Sensor
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to TAHM0
Documents and manuals
Veris TAHM0 Documents
Overview
Details for TAHM0
Temp | Duct Avg. | 12 Ft | 20k NTC
The TA series is a flexible TA sensor which averages the temperature read across the entire length of the copper tubing, making it ideal for duct temperature measurements. TA series sensors average the measured temperature across the duct in 12 ft lengths for the flexible probe.
Specifications
Item Number | TAHM0 |
Brand | Veris |
Application Zone | Plant Room |
Application | Chiller | Heat Exchangers |
Brand | Veris |
Dimension Depth | 1.8" (44 mm) |
Dimension Height | 4.2" (102 mm) |
Dimension Probe Diameter | 3/16" (4.8 mm) |
Dimension Probe Length | 12' (3.6 m) |
Dimension Width | 2.3" (58 mm) |
Electrical Wiring Size | 22 AWG (0.32 mm²) |
Enclosure Material | Galvanized Steel |
Measurement Type | Temperature |
Model | TAHM0 |
Mounting | Duct with Mounting Box |
Operating Temperature | -13 - 221 °F (-25 - 105 °C) |
Outputs | Resistive output |
Product Type | Sensor |
Range | TA |
Sensor Averaging Wire Length | 12 feet |
Sensor Configuration | Averaging |
Sensor | Temperature |
Temperature Calibration Certificate | None |
Temperature Sensor Type | 20k Ohm NTC Thermistor |
Warranty | 5 years |
