BGR-8320-00 | Trans | Freq in | Scaled Pls out | no enclsr | Veris

Programmable Flow Transmitter, Pulse

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to BGR-8320-00

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Veris BGR-8320-00 Documents

Datasheet More Info

Overview

Details for BGR-8320-00

Trans | Freq in | Scaled Pls out | no enclsr

3x0 programmable transmitters are capable of converting the frequency signal from any compatible flow sensors to a preferred output type (analog, scaled pulse, protocol). In addition to standard square wave signals, it can also accept a sine wave, making it a versatile transmitter for numerous applications. The 320 offer analog and scaled pulse output, respectively.

Compact - saves space in crowded enclosures
Programmable (units of measure, calibration, etc.) using computer with Windows based operating system, save installation time in the field by pre-programming the device
Transient suppression - complies with IEC-801-4 electrical burst, fast transient specification
Pulse output - isolated solid-state switch in any standard or custom flow total units; adjustable 50 ms to 1 s pulse output width in 50 ms increments

Specifications

Item Number	BGR-8320-00
Brand	Veris
Application	Flow transmitter
Field Programmable	Yes
Flow Measurement Range	Frequency range 4…1000 Hz
Operating Temperature	32 - 158 °F (0 °- 70 °C)
Output Specifications	Scaled Pulse
Outputs	Pulse output
Product Type	Transmitter
Range	320 BTU series
Totalizer Quantities	1
Totalizer Resettable	No
Warranty	1 year
