XVR13G04L | 130MM MIRROR RED 120VAC IP67 | Square D by Schneider Electric

Brand: Square DSKU: XVR13G04L
Square D | XVR13G04L
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to XVR13G04L
Jump to: Overview & Specifications Reviews

Overview Details for XVR13G04L

130MM MIRROR RED 120VAC IP67

Harmony XVR3 - 130mm Rotating Mirror Red 120VAC IP67 This red beacon is part of the range of rotating beacons Harmony XVR diameter 130mm. It is supplied complete and pre-cabled. Supply voltage is 120V AC and degree of protection is IP 66 and IP 67. It is designed for long distance signaling applications, thanks to the use of “super-bright” LED which provides good illuminating power, a long service life and reduced time for maintenance and also energy saving. It is used mainly in the iron and steel industry, on industrial handling vehicles or for safety applications.

Specifications

Range of Product
Harmony XVR
Product or Component Type
Prewired rotating mirror beacon
sound signalling
Without
device short name
XVR
mounting diameter
5.12 in (130 mm)
IP degree of protection
IP66 IEC 60529;IP67 IEC 60529
[Us] rated supply voltage
120 V AC
light source
High luminosity LED;red
Material
ABS (acrylonitrile butadiene-styrene) body part;PC globe
CAD overall width
5.12 in (130 mm)
CAD overall depth
5.12 in (130 mm)
Net Weight
2.18 lb(US) (0.99 kg)
Marking
CE
product mounting
By 3 M6 screws
[Uimp] rated impulse withstand voltage
4 kV
Current Consumption
42 mA
flashing frequency
2.7 Hz
Clamping Connection Capacity
1.25 mm²
AWG Gauge
AWG 18
Cable length
15.75 in (400 mm)
Standards
EN/IEC 60947-5-1;EN/IEC 60947-1
protective treatment
TC
Ambient Air Temperature for Storage
-31…158 °F (-35…70 °C)
Ambient air temperature for operation
-22…122 °F (-30…50 °C)
electrical shock protection class
Class II IEC 61140
Category
22617-XVC TOWER LIGHTS
Discount Schedule
XV
GTIN
3389119045308
Returnability
Yes
Country of origin
ID
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
12.01 in (30.5 cm)
Package 1 Width
7.87 in (20.0 cm)
Package 1 Length
7.87 in (20.0 cm)
Package 1 Weight
2.93 lb(US) (1.328 kg)
Unit Type of Package 2
S04
Number of Units in Package 2
6
Package 2 Height
11.81 in (30.0 cm)
Package 2 Width
15.75 in (40.0 cm)
Package 2 Length
23.62 in (60.0 cm)
Package 2 Weight
20.30 lb(US) (9.21 kg)
Warranty
18 months
