HOMT3020CP | Tandem mini circuit breaker, Homeline, 1 x 1 pole at 30A, 1 x 1 pole at 20A, 120/240 VAC, 10 kA AIR, plug in mount | Square D by Schneider Electric

Brand: Square DSKU: HOMT3020CP

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to HOMT3020CP

Jump to: Overview & Specifications Reviews

Overview Details for HOMT3020CP

Tandem mini circuit breaker, Homeline, 1 x 1 pole at 30A, 1 x 1 pole at 20A, 120/240 VAC, 10 kA AIR, plug in mount

HOMT Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. The HOMT circuit breaker is two single pole thermal magnetic circuit breakers manufactured in tandem. This tandem breaker occupies only one HOM pole space. Each single pole HOMT plug in circuit breaker provides an individual switching and tripping action. This tandem HOM miniature tandem breaker with plug in mounting is rated 30 A and 20 A at 120/240 V. This circuit breaker provides 10 kA breaking capacity. This tandem breaker will accept 14 AWG to 8 AWG copper or aluminum wire. The tandem breaker is 3.13 inches tall, 1.00 inches wide and 2.98 inches deep. HOMT tandem breakers are UL Listed. This Homeline Breaker comes in consumer packaging.

Specifications

Product: Miniature circuit-breaker
Range: Homeline
Current Rating: 30 A;20 A
Certifications: UL Listed
Voltage Rating: 120/240 V AC
Mounting Type: Plug-in
Number of Poles: 1P
Short Circuit Current Rating: 10 kA
Number of Spaces: 1
Circuit Breaker Type: Tandem
Ratings: HACR rated
Electrical Connection: Box lugs
Wire Size: AWG 14...AWG 8 aluminium/copper)1
Type of Packing: Consumer packaging
tightening torque: 35.40 lbf.in (4.0 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 8)
Height: 3.13 in (79.50 mm)
Width: 1 in (25.40 mm)
Depth: 2.98 in (75.69 mm)
Ambient air temperature for operation: 104 °F (40 °C)
Category: 00046-HOM/T 15-30A 1P; 15-60A 2P
Discount Schedule: DE3D
GTIN: 785901403852
Returnability: Yes
Country of origin: MX
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 1.00 in (2.54 cm)
Package 1 Width: 2.60 in (6.604 cm)
Package 1 Length: 3.20 in (8.128 cm)
Package 1 Weight: 6.88 oz (195.0 g)
Unit Type of Package 2: BB1
Number of Units in Package 2: 10
Package 2 Height: 3.40 in (8.636 cm)
Package 2 Width: 2.60 in (6.604 cm)
Package 2 Length: 10.20 in (25.908 cm)
Package 2 Weight: 4.53 lb(US) (2.055 kg)
Unit Type of Package 3: CAR
Number of Units in Package 3: 100
Package 3 Height: 11.00 in (27.94 cm)
Package 3 Width: 7.90 in (20.066 cm)
Package 3 Length: 17.40 in (44.196 cm)
Package 3 Weight: 46.35 lb(US) (21.024 kg)
