HOM240 | MINIATURE CIRCUIT BREAKER 120/240V 40A | Square D by Schneider Electric

Brand: Square DSKU: HOM240
Square D | HOM240
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to HOM240
Jump to: Overview & Specifications Reviews

Overview Details for HOM240

MINIATURE CIRCUIT BREAKER 120/240V 40A

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 40A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs. The box lugs will accept a wire range of 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Specifications

Product
Miniature circuit-breaker
Range
Homeline
Current Rating
40 A
Certifications
UL Listed
Voltage Rating
120/240 V AC
Mounting Type
Plug-in
Number of Poles
2P
Short Circuit Current Rating
10 kA
Number of Spaces
2
Circuit Breaker Type
Standard
Ratings
HACR rated
Electrical Connection
Box lugs
Wire Size
AWG 8...AWG 2 aluminium/copper)1
tightening torque
40.71 lbf.in (4.6 N.m) (AWG 8...AWG 2)
Height
3.13 in (79.50 mm)
Width
2 in (50.80 mm)
Depth
2.98 in (75.69 mm)
Ambient air temperature for operation
104 °F (40 °C)
Category
00046-HOM/T 15-30A 1P; 15-60A 2P
Discount Schedule
DE3D
GTIN
785901065302
Returnability
Yes
Country of origin
MX
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
1.60 in (4.06 cm)
Package 1 Width
2.60 in (6.6 cm)
Package 1 Length
3.10 in (7.87 cm)
Package 1 Weight
11.20 oz (317.52 g)
Unit Type of Package 2
BB1
Number of Units in Package 2
5
Package 2 Height
3.20 in (8.128 cm)
Package 2 Width
2.60 in (6.604 cm)
Package 2 Length
10.20 in (25.908 cm)
Package 2 Weight
3.58 lb(US) (1.624 kg)
Unit Type of Package 3
CAR
Number of Units in Package 3
50
Package 3 Height
10.40 in (26.416 cm)
Package 3 Width
6.90 in (17.526 cm)
Package 3 Length
16.60 in (42.164 cm)
Package 3 Weight
36.65 lb(US) (16.624 kg)
Warranty
Lifetime
