Documents: 3RV29022DF0

Datasheet

3RV29022DF0 | SHUNT RELEASE | AC 90-110V | 50/60HZ | Siemens Electrical

VOLTAGE RELEASE, AC 90...110V, 50/60HZ, 100% ED, AC 70...190V, 50/60HZ, 5SEC ED, DC 70...190V, 5SEC ED, WITH SPRING-L. CONNECTION, FOR CIRCUIT-BREAKERS, SZ S00/S0

Brand: Siemens ElectricalSKU: 3RV29022DF0

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to 3RV29022DF0

Jump to: Overview & Specifications Reviews

Overview Details for 3RV29022DF0

Specifications

Item Number	3RV29022DF0
Brand	Siemens Electrical
Height	1.580 IN
Length	3.980 IN
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage Us at AC 50HZ	90 V
Rated control supply voltage Us at AC 60HZ	90 V
Suitable for motor safety switch	FALSE
Suitable for off-load switch	FALSE
Suitable for overload relay	FALSE
Suitable for power circuit breaker	FALSE
Type of electric connection	Spring clamp connection
Voltage type for actuating	AC
Weight	0.02200 LB
Width	3.390 IN
