3RT25261BA40 | 4POL.CONTACTOR. AC3: 11KW. 12 VDC | Siemens Electrical

2NO+2NC contactor. AC3 11KW DC 12v 4-pole. 2NO+2NC. sz s0. screw terminal 1NO+1NC integr.

Brand: Siemens ElectricalSKU: 3RT25261BA40

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 3RT25261BA40

Item Number	3RT25261BA40
Brand	Siemens Electrical
Modular version	TRUE
Number of auxiliary contacts as normally closed contact	1
Number of auxiliary contacts as normally open contact	1
Number of main contacts as normally open contact	2
Number of normally closed contacts as main contact	2
Rated control supply voltage Us at DC	12 V
Rated operation current Ie at AC-1; 400 V	40 A
Rated operation current Ie at AC-3; 400 V	25 A
Rated operation power at AC-3; 400 V	11 kW
Rated operation power NEMA	11.032481249 kW
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	DC
Weight	1.46700 LB
