3RT20182AK61 | CONTACTOR S00 16A 120VAC 1NO SPRG | Siemens Electrical

Contactor, AC-3, 7.5KW/400V, 1NO, AC110v 50HZ, 120v 60HZ 3-pole, sz s00 spring-loaded terminal

Brand: Siemens ElectricalSKU: 3RT20182AK61

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 3RT20182AK61

Item Number	3RT20182AK61
Brand	Siemens Electrical
Height	2.850 IN
Length	3.200 IN
Modular version	TRUE
Number of auxiliary contacts as normally open contact	1
Number of main contacts as normally open contact	3
Rated control supply voltage Us at AC 50HZ	110 V
Rated control supply voltage Us at AC 60HZ	120 V
Rated operation current Ie at AC-1; 400 V	22 A
Rated operation current Ie at AC-3; 400 V	16 A
Rated operation current Ie at AC-4; 400 V	11.5 A
Rated operation power at AC-3; 400 V	7.5 kW
Rated operation power NEMA	7.354987499 kW
Type of electrical connection of main circuit	Spring clamp connection
Voltage type for actuating	AC
Weight	0.55500 LB
Width	2 IN
