3RT20181FB42 | CONTACTOR S00 16A 24VDC 1NC SCRW | Siemens Electrical

Contactor, AC-3, 7.5KW/400V, 1NC, DC 24V, w. integrated diode 3-pole, sz s00 screw terminal

Brand: Siemens ElectricalSKU: 3RT20181FB42

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 3RT20181FB42

Item Number	3RT20181FB42
Brand	Siemens Electrical
Height	3.800 IN
Length	4 IN
Modular version	TRUE
Number of auxiliary contacts as normally closed contact	1
Number of main contacts as normally open contact	3
Rated control supply voltage Us at DC	24 V
Rated operation current Ie at AC-1; 400 V	22 A
Rated operation current Ie at AC-3; 400 V	16 A
Rated operation current Ie at AC-4; 400 V	11.5 A
Rated operation power at AC-3; 400 V	7.5 kW
Rated operation power NEMA	7.354987499 kW
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	DC
Weight	0.65500 LB
Width	2.450 IN
