3RT20181AD02 | CONTACTOR S00 16A 42VAC 1NC SCRW | Siemens Electrical

CONTACTOR, AC-3, 7.5KW/400V, 1NC, AC 42V, 50/60 HZ, 3-POLE, SZ S00 SCREW TERMINAL

Brand: Siemens ElectricalSKU: 3RT20181AD02

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 3RT20181AD02

Item Number	3RT20181AD02
Brand	Siemens Electrical
Height	3.080 IN
Length	2.450 IN
Modular version	TRUE
Number of auxiliary contacts as normally closed contact	1
Number of main contacts as normally open contact	3
Rated control supply voltage Us at AC 50HZ	42 V
Rated control supply voltage Us at AC 60HZ	42 V
Rated operation current Ie at AC-1; 400 V	22 A
Rated operation current Ie at AC-3; 400 V	16 A
Rated operation current Ie at AC-4; 400 V	11.5 A
Rated operation power at AC-3; 400 V	7.5 kW
Rated operation power NEMA	7.354987499 kW
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	AC
Weight	0.61600 LB
Width	1.970 IN
