Documents: 3RT20171AP011AA0
3RT20171AP011AA0 | CONTACTOR S00 12A 230VAC 1NO SCRW VRT | Siemens Electrical
CONT, AC-3,5.5KW/400V, 1NO, AC 230
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to 3RT20171AP011AA0
Overview Details for 3RT20171AP011AA0
Specifications
Item Number | 3RT20171AP011AA0 |
Brand | Siemens Electrical |
Height | 3.080 IN |
Length | 2.450 IN |
Modular version | TRUE |
Number of auxiliary contacts as normally open contact | 1 |
Number of main contacts as normally open contact | 3 |
Rated control supply voltage Us at AC 50HZ | 230 V |
Rated control supply voltage Us at AC 60HZ | 230 V |
Rated operation current Ie at AC-1; 400 V | 22 A |
Rated operation current Ie at AC-3; 400 V | 0 |
Rated operation current Ie at AC-4; 400 V | 8.5 A |
Rated operation power at AC-3; 400 V | 5.5 kW |
Rated operation power NEMA | 5.516240624 kW |
Type of electrical connection of main circuit | Screw connection |
Voltage type for actuating | AC |
Weight | 0.48400 LB |
Width | 1.970 IN |
