3RT20152AK61 | CONTACTOR S00 7A 120VAC 1NC SPRG | Siemens Electrical

CONTACTOR_AC 3RT2015-2AK61-3RT2015-2AK61_3kW_120V

Brand: Siemens ElectricalSKU: 3RT20152AK61

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 3RT20152AK61

Item Number	3RT20152AK61
Brand	Siemens Electrical
Height	2.850 IN
Length	3.400 IN
Modular version	TRUE
Number of auxiliary contacts as normally open contact	1
Number of main contacts as normally open contact	3
Rated control supply voltage Us at AC 50HZ	110 V
Rated control supply voltage Us at AC 60HZ	120 V
Rated operation current Ie at AC-1; 400 V	18 A
Rated operation current Ie at AC-3; 400 V	0.291666666666667
Rated operation current Ie at AC-4; 400 V	6.5 A
Rated operation power at AC-3; 400 V	3 kW
Rated operation power at AC-4; 400 V	3 kW
Rated operation power NEMA	2.20649625 kW
Type of electrical connection of main circuit	Spring clamp connection
Voltage type for actuating	AC
Weight	0.560 LB
Width	1.950 IN
