3RH22622BB40 | CONTROL RELAY 6NO+2NC DC 24V SPRING | Siemens Electrical

Contactor relay, 6no+2NC, DC 24V, sz s00, spring-loaded terminal, permanent aux. switch, for suva applications

Brand: Siemens ElectricalSKU: 3RH22622BB40

The photo is for representation purposes only and may not be a photo of product being purchased.

Overview Details for 3RH22622BB40

Item Number	3RH22622BB40
Brand	Siemens Electrical
Coil Power Rating	4 W / 4 W
Coil Voltage	DC
Connection	spring-loaded terminals
Contact Configuration	2
Contact Rating	A600 / Q600
Height	2.950 IN
Length	5.150 IN
Mounting	screw and snap-on mounting onto 35 mm standard mounting rail
Operating Cycles	10
Operating Temperature	-25 °C ... 60 °C
Power Factor	-99999
Size	0.045 m / 0.07 m / 0.121 m
Special Features	TRUE
Sub Brand	SIRIUS
Type	Auxiliary contactor
Weight	0.76500 LB
Width	2 IN
