GSD346.1U | Damper Actuator | Non-Spring Return | 120 to 230 VAC | On/Off/Floating Point | 20 lb-in | SW | Siemens
Damper Actuator 20 lb-in 2-position/floating control, non-spring return, built in auxiliary switches, supply voltage 100 to 240 VAC. For low torque VAV applications and small dampers.
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to GSD346.1U
Documents and manuals
Siemens GSD346.1U Documents
Datasheet(OpenAir GSD Series Non-Spring Return. 20 lb-in (2 Nm). Rotary Electronic Damper Actuators Technical Instructions)Datasheet(OpenAir GSD Series. Non-Spring Return. 20 lb-in (2 Nm). Rotary Electronic Damper Actuators Submittal Sheet)Installation instruction(OpenAir GSD Series. Non-Spring Return Rotary Electronic Damper Actuators Installation Instructions) Installation Instructions More Info
Overview
Details for GSD346.1U
Damper Actuator | Non-Spring Return | 120 to 230 VAC | On/Off/Floating Point | 20 lb-in | SW
Damper Actuator 20 lb-in 2-position/floating control, non-spring return, built in auxiliary switches, supply voltage 100 to 240 VAC. For low torque VAV applications and small dampers.Specifications
- Actuator Type
- Non-spring return
- Actuation Style
- Rotary
- Control or Fire/Smoke Type
- Control Damper
- Plenum or Standard Rating
- Standard
- Torque
- 20 lb-in
- Fail Safe
- No
- Control Signal
- 2-position , Floating control
- Positioning time
- Runtime for 90° 30 s
- Position feedback
- No
- Power consumption
- Running: 4.5 VA (1.8 W), Holding: 2.4 VA (0.9 W)
- Ambient temperature, operation
- -25 to 130 °F, -32 to 55 °C
- Operating voltage
- 120-230 VAC
- Supply Voltage
- 120 to 230 VAC
- Frequency
- 50/60 Hz
- Auxiliary Switch
- Yes
- Auxiliary switch
- 2
- Cable length
- 3 ft
- Dimensions (W x H x D)
- 2.83 x 5.86 x 2.45 in
- Material, housing
- IP54 enclosure, Plenum rated rugged plastic
