GPC326.1U | Damper Actuator | Spring Return | 120 to 230 VAC | On/Off | 35 lb-in | SW | Siemens

OpenAir GPC Series Electric Damper Actuator, spring return, 35 lb-in. For use on economizer dampers and small control dampers

Siemens | GPC326.1U
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to GPC326.1U
Jump to: DocumentsOverview SpecificationsReviews

Documents and manuals

Siemens GPC326.1U Documents

Datasheet(OpenAir GPC Series Spring Return. 35 lb-in (4 Nm). Rotary Electronic Damper Actuators Technical Instructions)Datasheet(OpenAir GPC Series. Spring Return. 35 lb-n (4 Nm). Rotary Electronic Damper Actuators Submittal Sheet)Mounting instruction(OpenAir GPC Series. Spring Return. 35 lb-in (4 Nm) Electronic Damper Actuators Installation Instructions) Installation Instructions More Info

Overview

Details for GPC326.1U

Damper Actuator | Spring Return | 120 to 230 VAC | On/Off | 35 lb-in | SW

Damper actuator spring return, 35 lb-in 2-position control. 120 to 230 VAC with fixed dual built in auxiliary switches and plenum rated. For use on small control dampers

Specifications

Actuator Type
Spring return
Actuation Style
Rotary
Control or Fire/Smoke Type
Control Damper
Plenum or Standard Rating
Standard
Torque
35 lb-in
Fail Safe
Yes
Control Signal
2-position
Positioning time
Runtime for 90° 60 s
Position feedback
No
Power consumption
Running: 4.6 VA (2.4 W), Holding: 3.5 VA (1.7 W)
Ambient temperature, operation
-25 to 130 °F, -32 to 55 °C
Angular rotation
90°
Operating voltage
120-230 VAC
Supply Voltage
120 to 230 VAC
Frequency
50/60 Hz
Auxiliary Switch
Yes
Auxiliary switch
2
Cable length
3 ft
Dimensions (W x H x D)
2.83 x 5.61 x 2.48 in
Material, housing
NEMA 1, Plenum rated rugged plastic
