274-03167 | Valve assy 2W NO, 1
274-03167 | Valve assy 2W NO, 1" 10Cv Eq Pct Brass Trim FxF, Prop El-Hydraul Act SR | Siemens
Siemens | 274-03167
The photo is for representation purposes only and may not be a photo of product being purchased.

274-03167 | Valve assy 2W NO, 1" 10Cv Eq Pct Brass Trim FxF, Prop El-Hydraul Act SR | Siemens

SKU: 274-03167Brand: SiemensCondition: New

Details for 274-03167

Valve assy 2W NO, 1" 10Cv Eq Pct Brass Trim FxF, Prop El-Hydraul Act SR

Flowrite 599 Series Valve Assembly

Valve assy 2W NO, 1" 10Cv Eq Pct Brass Trim FxF, Prop El-Hydraul Act SR

Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator. The 2-way, normally open, 1-inch, 10 Cv valve assembly is ANSI Class 250 and has an equal percentage characteristic, brass trim, and female x female end connections.

The Flowrite 599 Series two-way valve bodies, ANSI 250, work with a Flowrite series actuator with a 3/4-inch (20 mm) stroke. Typical applications include control of hot or chilled water, 50% water-glycol solutions, or steam.

Read More
Brand: SiemensSKU: 274-03167
List Price
$2,158.53
$820.24
Availability: This product is currently available to purchase
Orders over $999 ship FREE
Shipping and Returns Terms

Siemens 274-03167 Documents

Speak With a Technical Expert

Call (847) 773-0645

Hours: 9am - 7pm CDT M-F

Details for 274-03167

Valve assy 2W NO, 1" 10Cv Eq Pct Brass Trim FxF, Prop El-Hydraul Act SR

Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), spring return, 24 Vac electro-hydraulic actuator. The 2-way, normally open, 1-inch, 10 Cv valve assembly is ANSI Class 250 and has an equal percentage characteristic, brass trim, and female x female end connections.

The Flowrite 599 Series two-way valve bodies, ANSI 250, work with a Flowrite series actuator with a 3/4-inch (20 mm) stroke. Typical applications include control of hot or chilled water, 50% water-glycol solutions, or steam.

Description

Features

  • ANSI Leakage Class IV (0.01% of Cv).
  • Normally-open and normally-closed configurations.
  • Cartridge-type packing.
  • Equal percentage flow characteristics with either brass or stainless steel trim.
  • Linear flow characteristic with stainless steel trim.
  • High temperature packing available on linear valves.
  • Direct-coupled universal bonnet.
