267-06050 | Valve assy Hi Temp 2W NC 2-1/2" 63Cv Lin SS Trim Flng Prop El-Hydraul Act NSR | Siemens

Flowrite 599 Series Valve Assembly features a proportional control (0 to 10 Vdc or 4 to 20 mA), non-spring return, 24 Vac electro-hydraulic actuator. The 2-way, normally closed, 2-1/2-inch, 63 Cv valve assembly with 3/4-inch stroke is ANSI Class 125 and has a linear characteristic, stainless steel trim, high temp packing, and flanged end connections.

Siemens | 267-06050
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to 267-06050

Overview

Details for 267-06050

Valve assy Hi Temp 2W NC 2-1/2" 63Cv Lin SS Trim Flng Prop El-Hydraul Act NSR

Specifications

Valve Body Style
Stroke-Globe
End Connection
Flanged
Connecting thread
Direct-coupled universal bonnet
Material, valve body
Cast iron ASTM A126 Class B
Material, inside set
Body Trim: Stainless Steel , Stem: Stainless steel ASTM A582 Type 303 , Plug: Bronze , Seat: Single seat , Normal Duty Packing: EPDM O-rings
Medium
Saturated steam , Water , Water with anti-freeze , Steam
Rangeability
100:1
High temperature
YES
Port Configuration
2-Way Normally closed
Medium temperature
20…337 ºF
Stroke
20 mm, 0.75 " mm
Stroke, inch
0.75 "
Stroke, mm
20 mm
Valve Actuator Type
Electronic
Supply Voltage
24 VAC
Positioning time
Open:30 s, Close:15 s
Power consumption
17 VA
