VA-9313-556-5-14 | VB: 4 in, 3W Mix, Globe, FLG, UC, BR, 170 cv, 11 PSI; Act (MA41-7153): Elec, 2Pos, SR, NC, 24 VAC/VDC, 22-30 VDC, App, 133 in-lb, Rotary, N1/N2 | Schneider Electric

VB: 4 in, 3W Mix, Globe, FLG, UC, BR, 170 cv, 11 PSI; Act (MA41-7153): Elec, 2Pos, SR, NC, 24 VAC/VDC, 22-30 VDC, App, 133 in-lb, Rotary, N1/N2

• Body Size: 4 in
• Configuration: 3-Way Mixing
• Type: Globe
• Connection: Flanged
• Stem Flow Action: Stem up, mixing closed A to AB
• Material Trim: Brass
• Flow Coefficient: 170 cv
• Close-Off Pressure: 11 PSI
• Actuator Type: Electric
• Control Signal: 2-Position (On/Off)
• Loss of Power Type: Spring Return
• Loss of Power Position: Up/Retract A closed
• Power Input Voltage: 24 VAC/VDC, 22 to 30 VDC
• Leads and Connections: 3 ft Appliance
• Torque: 133 in-lb
• Mechanical Movement: Rotary
• Protection Rating: NEMA 1, NEMA 2

• Valve Body: VB-9313-0-5-14
• Valve Linkage: AV-607-1
• Actuator: MA41-7153
• Actuator Range: SmartX Actuator
