M9102-AGA-3S | ROTARY ACTUATOR; 18 IN-LB; NSR; 30 SEC; 90 DEG; 24 VAC | Johnson Controls
Documents and manuals
Johnson Controls M9102-AGA-3S Documents
Overview
Details for M9102-AGA-3S
ROTARY ACTUATOR; 18 IN-LB; NSR; 30 SEC; 90 DEG; 24 VAC
Description
The M9102 and M9104 Series Actuators are directmount, non-spring return electric actuators that operate on AC 24 V or 100 to 240 VAC power. These motor-driven actuators provide floating control (AGA), floating control with automatic shutoff (IGA), proportional control with selectable 0-10 or 2-10 VDC (GGA), and line voltage power supply (IUA). The -2S models are equipped with plenum cables, and the -3S models are equipped with terminal blocks.
All models are compact in size and are easily installed on VAV boxes, Variable Air Volume and Temperature (VVT) two-position zone applications, or small- to mediumsized dampers with a round shaft up to 1/2 in. (13 mm) in diameter or a 3/8 in. (10 mm) square shaft.
The M9102 Series Electric Non-Spring Return Actuators provide a running torque of 18 lb·in (2 N·m), and the nominal travel time is 30 seconds at 60 Hz (36 seconds at 50 Hz) for 90° of rotation.
The M9104 Series Electric NonSpring Return Actuators provide a running torque of 35 lb·in (4 N·m), and the nominal travel time is 60 seconds at 60 Hz for 90° of rotation. Refer to the M9102-AGA-2S, -3S and M9104-xGA-2S, -3S Series Electric Non-Spring-Return Actuators Product Bulletin(LIT-1201742) for important product application information.
- Damper Actuator
- 24 VAC
- Floating Point w/o Timeout
- Non-Spring Return
- 18 in-lb Torque
- M3 Screw Terminals
- 30 sec Runtime
- NEMA 1
- 0000 - 0025 IN-LB
Specifications
Item Number | M9102-AGA-3S |
Brand | Johnson Controls |
Actuator Type | Damper |
Category | Dampers & Actuators |
Control Input | Floating |
End Switch | No |
Housing | NEMA 1 |
Section | Electric Actuators |
Section | Valves & Actuators |
Spring Return | Non-Spring Return |
SubCategory | Electric Actuators |
Torque | 18 in-lb |
Voltage | 24V |
