Overview

Details for HMC200

Multiparameter (4-20 input) Controller Indicating Transmitters

Hayward’s HMC200 Indicating single-channel multi-parameter controller offers advanced features, a bright LCD display and a complete NEMA 4X enclosure. The HMC200 can accept flow, and analytical (pH, ORP, Conductivity) inputs, display parameter readings and transmit signals to DCS/PLC/SCADA systems for monitoring and control purposes. The HMC220 accepts two input channels, including the HLS level sensor and HEX magnetic flow meter, as well as a range of analytical inputs.

• pH, ORP, conductivity & flow parameters available
• Highly visible large backlit LCD display
• Flexible and easy calibration, including multi-point conductivity calibration for acids and bases
• 4-20mA process output with range scaling and PID Control
• Universal mounting hardware for surfaceand panel mounting
• Compatible with Hayward HMC differential pH/ORP sensors, 500-series combination style pH/ORP sensors, HMC200 Series conductivity sensors, and most pulsed flow sensors
• Two 4-20 mA output, with range scaling and temperature or flow totalizer option
• Three control/alarm relays with temperature or flow totalizer output option

Specifications

Item Number	HMC200
Brand	Hayward
Category	Instrumentation
Class
Model	HMC200
Power Type	AC/DC
Subtype	HMC200 Series Multi Parameter Controller
Suby Category	Controllers and Displays
