102228LF | 1/3 HP, HD3 AB Bronze Circulator Pump, Lead Free | Bell & Gossett

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to 102228LF

Jump to: Documents Overview Specifications Reviews

Documents and manuals

Bell & Gossett 102228LF Documents

Datasheet Catalog PartS & Accessories Installation Instructions

Overview

Details for 102228LF

1/3 HP, HD3 AB Bronze Circulator Pump, Lead Free

The Series 100 oil lubricated motor is specifically designed for the Series 100, and its resilient mounting provides quiet, dependable service with minimum annual lubrication. UL and CSA listings are standard. Series 100's three-piece, oil lubricated design provides for easy field service with bearings, shaft and seal all housed in an assembly which can be easily repaired or replaced. The design of this motor, combined with its overall hydraulic performance, allows the Series 100 to overcome system related noise caused by valves, fittings, or piping.

Specifications

Item Number	102228LF
Brand	Bell & Gossett
Amperage	4.2/2.1
Application	Heating
Connection Size	3"
Connection Type	Flanged x Flanged
Family	CIRCULATOR PUMPS
Flow Range (GPM)	0-115
Head Range (ft.)	5-19
Hertz	60
Horse Power	1/3
HP	1/3
Material	Bronze
Max Flow (GPM)	115
Max Head (Ft)	19
Max Pressure (PSI)	125
Max Temp (F)	225°F
Min Head (Ft)	5
Phase	1
Pump Type	Bronze Pumps
Pump Type	Circulator Pumps
RPM	1725
Type	Pump
Voltage	115v
