How to multiplex Pulse signal

Converts pulse width modulated signals into a four (4) or an eight (8) relay output. The DMUX features the following:

  1. Multiplexes a single output to eight (or 4), reducing output point cost
  2. 4 or 8 relay versions, each relay has N.O. and N.C. contacts (Form C)
  3. Accepts a relay, dry contact closure, transistor or triac signal
  4. Individual Hand/Off/Auto override jumpers are standard, switches are optional.
  5. Use DMUX to control multiple valves, lighting contactors, or any on/off electrical or pneumatic (through e/p relay) load.
Order Number
Type
Relay Rating
Electrical Connections

Features
DMUX8J
Pulse to 8 Relay Transducer
2 amps max. resistive at 24 volts
Screw terminals for 22 to 14 gage wire
Jumpers for hand/off/auto, 4 modes of relay control: Sequence, individual, 1 of 8, and RTU
DMUX4J
Pulse to 4 Relay Transducer
2 amps max resistive at 24 volts
Screw terminals for 22 to 14 gage wire
Jumpers for hand/off/auto, 4 modes of relay control: Sequence, individual, 1 of 8, and RTU (Roof Top Unit)

    How to multiplex Pulse signalSee All PWM Products
