0011-CF-USK | Circulator Pump | Cast Iron | 1/8 HP | 115V | Single Phase | 3250 RPM | Shutoff Flanged (3/4") | Integral Flow Check | Series 0011 | Taco
Documents and manuals
Taco 0011-CF-USK Documents
Overview
Details for 0011-CF-USK
Circulator Pump | Cast Iron | 1/8 HP | 115V | Single Phase | 3250 RPM | Shutoff Flanged (3/4") | Integral Flow Check | Series 0011
![](https://supplyfile.com/images/taco/badge_taco.png)
Rugged, Versatile, Quick and Easy to Install
With their self-lubricating design and no mechanical seal, Taco 00 ® Series Cartridge Circulators provide unmatched reliability that makes them maintenance free. Every Taco 00 ® Series Cartridge Circulator and 00 IFCm® circulator features a field-replaceable cartridge that contains all the moving parts. Replacing the cartridge rebuilds the circulator, so field service is fast and simple. 00 ® Series Cartridge Circulators wide variety of configurations, flange orientation, mounting and other options, materials and capabilities provide you with great performance in a broad range of applications.
Taco 00 IFC ® Cartridge Circulators feature an Integral Flow Check (IFC) that eliminates the additional installation costs that go along with separate in-line flow checks, improves system performance and further reduces maintenance.
Performance Data
Flow Range: 0 – 52 GPM
Head Range (ft): 0 – 32′
HP: 1/40 – 1/6
Connection Sizes: ¾” – ½” Flanged, ¾” Sweat, NPT or Union
Features
- Standard High Capacity Output
- Compact Design
- Quiet, Efficient Operation
- Direct Drive–Low Power Consumption
- Unique Replaceable Cartridge Design
- Field Serviceable
- Self lubricating
- No Mechanical Seal
- Unmatched Reliability–Maintenance Free
- Optional Integral Flow Check (IFC®)
- Prevents Gravity Flow/Reverse Flow
- Eliminates Separate In-Line Flow Check
- Reduces Installed Cost
- Improves System Performance
Applications
- Hydronic Heating System
- Hydro-Air Fan Coils
- Zoning with Circulators
- Chilled Water Cooling
- Domestic Water Systems
- Radiant Heating Systems
The TacoGenie delivers hot water comfort and convenience to faucets and taps "On Command" 24 hours a day, and at the same time it saves water, energy and money. Have hot water at your fingertips whenever you turn thefaucet. Stop wasting water as you wait for cold to turn to hot. Stop burning energy as you wait for warm to turn warmer. The TacoGenie™ puts an end to the waste, and the wait, forever.
How the TacoGenie Works:
The TacoGenie is a small, silent pump attached to your hot and cold water lines in the cabinet under your most remote kitchen or bath fixture. When TacoGenie is activated, the cool water you normally let run down the drain is circulated back to the water heater through the cold water line.
Instantly the pump circulates hot water from the water heater, and returns the cooled water back through the cold water line. When the hot water arrives at the faucet, the TacoGenie heat sensor and control board shut off the pump to prevent pumping excess hot water into the cold water line.
Activate the TacoGenie only when you need it:
TacoGenie only runs when you tell it to, and it’s smart enough to know when the water currently in the line is hot enough. TacoGenie can be activated with the push of a button, or with an optional wireless remote transmitter/receiver or optional hard-wired motion sensor.
Easy To Install:
The TacoGenie not only saves water and energy, it saves in construction costs as well. No new return line is necessary; no need to drain the system; no demolition and repair. In fact, TacoGenie can be installed in just eight simple steps
A great way to save:
TacoGenie operates 24 hours a day to save you water, energy and money. What’s more, it’s made by Taco, known by plumbing professionals as a world leader in high quality hydronic components since 1920. The average home may waste over 12,000 gallons of water per year while waiting for hot water. Stop wasting and start saving with a TacoGenie.
- Runs only when activated by the user.
- Is available 24 hours per day / 7 days a week.
- Automatically senses when water is hot enough.
- Saves water, energy and money.
- Saves construction costs; No new return line needed and no need to drain the system.
- Simple installation.
Specifications
Item Number | 0011-CF-USK |
Brand | Taco |
Amperage | 1.76 |
Amps | |
Application | Heating |
Connection Type | Flanged x Flanged |
Connection | Shutoff Flanged (3/4") |
Flow Range (GPM) | 0-31 |
Head Range (ft.) | 0-26 |
Hertz | 60 |
Horse Power | 1/8 |
HP | 1/8 HP |
Material | Cast Iron |
Material | Stainless Steel |
Max Flow (GPM) | 8 |
Max Flow | |
Max Head (Ft) | 26 |
Max Head Pressure | |
Max Pressue | |
Max Pressure (PSI) | 125 |
Optional | |
Optional | Integral Flow Check |
Phase | 1 |
Phase | Single Phase |
Pump Type | Circulator Pump |
RPM | 3250 |
RPM | 3250 RPM |
Series | Series 0011 |
Temperature Range (F) | 40°F to 230°F |
Type | Non-Dedicated |
Type | Pump |
Voltage | 115v |
