BMXDDI3202K | discrete input module X80 - 32 inputs - 24 V DC positive | Square D by Schneider Electric

Brand: Square DSKU: BMXDDI3202K

The photo is for representation purposes only and may not be a photo of product being purchased.

Search products similar to BMXDDI3202K

Jump to: Overview & Specifications Reviews

Overview Details for BMXDDI3202K

discrete input module X80 - 32 inputs - 24 V DC positive

This discrete input module is part of the Modicon X80 modules. It has 32 isolated inputs and it is supplied with 24V DC. this input module with 40-way connectors is designed, for use in conjunction with the TeSys Quickfit mounting system. It occupies a single slot on the rack and it has a case which provides IP 20 protection of the electronics.

Specifications

Range of Product: Modicon X80
Product or Component Type: Discrete input module
Discrete input number: 32
discrete input type: Isolated
input type: Current sink (logic positive)
discrete input voltage: 24 V DC positive
discrete input current: 2.5 mA
input compatibility: With 2-wire/3-wire proximity sensors IEC 60947-5-2, With 2-wire/3-wire proximity sensors IEC 61131-2 Type 1
Sensor power supply: 19...30 V
current state 1 guaranteed: >= 2 mA
current state 0 guaranteed: <= 0.5 mA
Input impedance: 9600 Ohm
insulation resistance: > 10 MOhm 500 V DC
power dissipation in W: 3.9 W
DC typical response time: 4 ms
DC maximum response time: 7 ms
Paralleling of inputs: No
typical current consumption: 121 mA 3.3 V DC
MTBF reliability: 696320 H
protection type: 1 external fuse per group of channel 0.5 A fast blow, reverse polarity protection
voltage detection threshold: < 14 V DC sensor fault, > 18 V DC sensor OK
status LED: 1 LED (Green) module operating (RUN), 1 LED per channel (Green) channel diagnostic, 1 LED (Red) module error (ERR), 1 LED (Red) module I/O
Net Weight: 0.25 lb(US) (0.112 kg)
IP Degree of Protection: IP20
Directives: 2014/35/EU - low voltage directive, 2014/30/EU - electromagnetic compatibility
dielectric strength: 1500 V AC 50/60 Hz 1 minute, primary/secondary, 500 V DC 1 minute, between group of channels
vibration resistance: 3 gn
shock resistance: 30 gn
Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)
Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)
relative humidity: 5…95 % 131 °F (55 °C) without condensation
operating altitude: 0...6561.68 ft (0...2000 m), 2000...5000 m with derating factor
Category: 18160-MODICON M340
Discount Schedule: PC34
GTIN: 3595863910018
Returnability: Yes
Country of origin: ID
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 2.12 in (5.373 cm)
Package 1 Width: 4.32 in (10.974 cm)
Package 1 Length: 4.55 in (11.554 cm)
Package 1 Weight: 5.45 oz (154.4 g)
Unit Type of Package 2: S02
Number of Units in Package 2: 15
Package 2 Height: 5.91 in (15.0 cm)
Package 2 Width: 11.81 in (30.0 cm)
Package 2 Length: 15.75 in (40.0 cm)
Package 2 Weight: 5.51 lb(US) (2.5 kg)
Warranty: 18 months
