FP F3890XS1 + RT080 | 2 WAY Industrial Ball Valves | Full Port, NPT Female Bronze Body & Stainless Steel Ball | R series low voltage Actuators | 360 in.lb | 24V | ON/OFF | Floating | Electronic Fail Safe | End Switch | Neptronic (OBSOLETE)
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to FP F3890XS1 + RT080
Overview
Details for FP F3890XS1 + RT080
DISCONTINUED MODEL, CONTACT TECHNICAL SUPPORT FOR REPLACEMENT OPTIONS
2 WAY Industrial Ball Valves | Full Port, NPT Female Bronze Body & Stainless Steel Ball | R series low voltage Actuators | 360 in.lb | 24V | ON/OFF | Floating | Electronic Fail Safe | End Switch
The Industrial Ball Valve Series are actuated Ball Valves that provide digital or analog control of hot water, chilled water containing up to 50% glycol or 15 PSI steam. Each unit is comprised of a rotary actuator and linkage assembly coupled to the valve body that offers, high pressure differential Close-Off. The standard full port design is less restrictive providing high flow characteristics with low pressure drops. Valve sizes range from 1/2 inch to 3 inches with a maximum valve body rating of 600 PSIG for a two way. These low profile, compact units can be installed with ease in the often tight, restricted areas found in unit ventilators, fan coils, terminal reheat coils and larger air handlers.Specifications
Item Number | FP F3890XS1 + RT080 |
Brand | Neptronic |
Control Input | Floating |
Control Valves Type | Ball Valves |
CV/GPM | 389 |
End Switch | Yes |
Spring Return | Electronic Fail-Safe |
Valve Size | 2"-2 WAY |
Voltage | 24V |
