TBH2300A0SV0000 | 3" CPVC TBH Series Ball Valve, SOC Ends, FPM Seals | Hayward
Overview
Details for TBH2300A0SV0000
3" CPVC TBH Series Ball Valve, SOC Ends, FPM Seals
The TBH Series features a low maintenance design with its new patent pending System2™ Sealing Technology for sizes up to 2”/DN50. Sizes 2-1/2” through 6” feature have energized PTFE seats with backing O-ring as standard. All seats are reversible to allow easy field rebuild. Assisting users in protecting property and life, a standard integral lock-out feature secures onto the body of the valve. Actuator ready design with ISO 5211 pattern – on all sizes. Available in sizes 1/4˝ through 6” / DN15 – DN150 in PVC and CPVC materials. The TBH Series are fully pressure rated for 250 PSI / PN16 at 70°F/23°C non-shock up to 2”/DN50. Sizes 2-1/2”/DN65 – 4”/DN100 sizes are pressure rated for 235psi at 70°F non-shock. Lastly, the TBH is available with IPS or DIN/EN and JIS socket, threaded and flanged end connections for global use. “Patented” & Other Patents Pending” Pat. No.: 11,131,404.
• Full 250 psi / PN16 Rating up to 2”/DN50 and 235psi/PN16, Non-Shock at 70°F / 23°C.• Integral ISO 5211 Mounting Pad for Easy Actuation
• Standard Lock-Out Plate, Lock-Out / Tag-Out for up to 4 Locks
• System2™ Sealing Technology Seat Carrier Design for sizes up to 2”/DN50– Patent Pending
• Permanent Laser Markings, Eliminates Labels
• System friendly "Molded-In" Footpad for Skid or Panel Mount
• UV Resistant Sure Grip Ergonomic Handle
• FPM or EPDM Seals
• Double O-Ring Stem Seals
• Reversible PTFE Seats - Standard
• Easy Replacement for Existing Hayward TB Series
Specifications
Item Number | TBH2300A0SV0000 |
Brand | Hayward |
Category | N/A |
Category | True Union Ball Valves |
Chassis Description | Large Diameter Body |
Class | N/A |
Cv Coefficient | 490 |
Cv Coefficient | 490.0000 |
End Connection Type | Socket |
End Connection | Socket |
Flow Configuration | Bi-directional |
Handle Material | GFPP |
Material | CPVC |
O-Ring Material | FPM |
Operating Pressure [Max] | 16 bar 235 psi |
Operation Type | Manual |
Pipe Size | 3 in |
Pressure Rating | 235 PSI |
Sealing Material | FPM |
Seat Material | PTFE |
Series | TBH |
Series | TBH Series True Union Ball Valves |
Size | 3" |
Sub Category | N/A |
SubCategory | TBH Series Ball Valves |
Subtype | Ball Valves |
Subtype | Industrial Ball Valves |
Type | Thermoplastic Valves |
Valve Material | CPVC |
Valve Type | Ball |
