TSX3-500132 | Digital refrigeration temperature switch | three outputs | two temperature probe inputs | 115V supply power | with red display. | Dwyer
Digital refrigeration temperature switch, three outputs, two temperature probe inputs, 115V supply power, with red display.
Documents and manuals
Dwyer TSX3-500132 Documents
Overview
Details for TSX3-500132
Digital refrigeration temperature switch | three outputs | two temperature probe inputs | 115V supply power | with red display.
SERIES TSX3 DIGITAL REFRIGERATION TEMPERATURE SWITCH
The Series TSX3 Digital Refrigeration Temperature Switch was designed to control the compressor, fan, and defrost in refrigeration applications. This generation of controls has field selectable engineering units and temperature probe types in order to reduce the combination of parts that need to be stocked. A built-in real time clock is used for HACCP logging of temperature alarms caused by temperatures out of their set limits or loss of power. The Intelligent Defrost parameters manage the defrost cycle in order to save energy cost. The digital input can be used to remotely trigger a defrost cycle, monitor cooler door status, or act as an external alarm. For programming multiple units, the model TS2-K configuration key can be used to quickly download parameter settings.
Product Applications
- Refrigerators
- Field selectable °F or °C
- Real time clock
- HACCP alarm logging
- Configuration key
- 2 or 3 output models for complete refrigerator control
- 2 temperature sensor and 1 digital contact inputs
Specifications
- Series
- TSX3 DIGITAL REFRIGERATION TEMPERATURE SWITCH
- Category/Type
- Temperature
- Type
- Switches
- Series
- TSX3 DIGITAL REFRIGERATION TEMPERATURE SWITCH
- Probe Range
- PTC: -58 to 302°F (-50 to 150°C); NTC: -58 to 230°F (-50 to 110°C).
- Input
- PTC (1000 Ω @ 25°C); NTC (10K Ω @ 25°C); Digital Input Contact.
- Output
- All models SPST NO relay resistive load 16 A; inductive load 5 A; 10 FLA; 60 LRA @ 240 VAC; dual output models also include 8 A resistive; 3 A inductive SPDT @ 240 VAC; three output models also include 8 A resistive SPST NO @ 240 VAC; 5 A resistive SPST NO @ 240 VAC.
- Horsepower Rating
- 1HP @ 240 VAC.
- Control Type
- On/Off.
- Power Requirement
- 115 VAC; 230 VAC; 12 VAC/VDC; 24 VAC/DC (±10%) depending on model.
- Power Consumption
- 3.6 VA (115/230/24 V); 1.5 VA (12 V).
- Accuracy
- ±1% FS.
- Display
- 3 digits plus sign.
- Resolution
- 0.1°.
- Memory Backup
- Non-volatile memory.
- Ambient Temperature
- 32 to 131°F (0 to 55°C).
- Weight
- 2.3 oz (65 g).
- Front Protection
- IP65 (NEMA 4X).
- Agency Approvals
- CE; cURus.
