SG3-B10721N | 1.5" SS gage | 1/8" npt bottom connection | range 200 psi | Dwyer
1.5" SS gage, 1/8" npt bottom connection, range 200 psi
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to SG3-B10721N
Documents and manuals
Dwyer SG3-B10721N Documents
Overview
Details for SG3-B10721N
See catalog product page for full listing
1.5" SS gage | 1/8" npt bottom connection | range 200 psi
SERIES SG3 1.5" INDUSTRIAL PRESSURE GAGE
2.5% FS Accuracy, 316 SS Wetted Parts, Dual PSI/Bar x100 kPa Scales
The Series SG3 Industrial Pressure Gages have dual psi and bar (x100 kPa) scales with ±2.5% full-scaleaccuracy. The Series SG3 gages are designed with 304 SS housings and 316 SS wettedparts for excellent chemical compatibility. These gages cover a wide variety of ranges fromfull vacuum to 300 psi. Units can withstand ambient temperatures up to 140°F (60°C).Bottom or back 1/8" NPT connection options available.
Calibration Option available under Accessories.
Product Applications
- Vacuums in pneumatic conveying lines
- Positive pressure in compressed air headers
- Corrosive ambient environments
- Stainless steel housing to resist ambient corrosion for longer service life in harshenvironments
- Good accuracy gage for value-sensitive applications requiring more precisemeasurement and where vibration is a concern
- Back or bottom mounting and compact size provides for mounting with dimensionallimitations
Specifications
- Series
- SG3 1.5" INDUSTRIAL PRESSURE GAGE
- Category/Type
- Pressure
- Type
- Single Pressure
- Series
- SG3 1.5" INDUSTRIAL PRESSURE GAGE
- Service
- Compatible gases and liquids.
- Wetted Materials
- 316 L SS tube; 316 SS connector.
- Housing
- 304 SS.
- Lens
- Polycarbonate.
- Accuracy
- 2.5% FS.
- Pressure Limit
- FS range.
- Temperature Limits
- -4 to 140°F (-20 to 60°C).
- Size
- 1.5" (40 mm).
- Process Connections
- 1/8" male NPT.
- Weight
- 2.4 oz (70 g) bottom; 2.5 oz (72 g) back.
