SCT20-103 | Current transducer | split core | 0-10 VDC output | range 20/100/150A | Dwyer
Current transducer, split core, 0-10 VDC output, range 20/100/150A
The photo is for representation purposes only and may not be a photo of product being purchased.
Search products similar to SCT20-103
Documents and manuals
Dwyer SCT20-103 Documents
Overview
Details for SCT20-103
See catalog product page for full listing
Current transducer | split core | 0-10 VDC output | range 20/100/150A
Series SCT Current Transformer
Optional Auxiliary, Relay Output, Split Core
The Series SCT Current Transformers continuously measure the current consumption of pumps, fans, boilers, solar panels and chillers for use in energy monitoring. Current or voltage outputs can be scaled using a slider switch to select between three factory set ranges. Split core configuration allows the current transformer to be installed on new and existing installations. Snap-on mounting bracket allows for quick installation of replacement transformers. An optional 10 A command relay can snap onto the current switch, which eliminates the need to mount an additional relay.
Specifications
- Series
- SCT Current Transformer
- Category/Type
- Process Control
- Type
- Current Transformers / Switches
- Series
- SCT Current Transformer
- Amperage Range
- 30/60/120 A or 20/100/150 A (depending on model).
- Continuous Operating Current
- 120 A or 150 A (depending on model).
- Output
- 4 to 20 mA; 0 to 5 VDC; 0 to 10 VDC (depending on model). Optionalrelay NO SPST; 10 A @ 260 VAC; 5 A @ 30 VDC.
- Power Requirements
- Self-powered or 24 VDC (depending on model).
- Accuracy
- ±2% from 10 to 100% of selected range.
- Temperature Limits
- 5 to 140°F (-15 to 60°C).
- Humidity Limits
- 0 to 95% non-condensing.
- Response Time
- 2 s.
- Isolation Voltage
- 600 VAC RMS.
- Frequency
- 50/60 Hz.
- Enclosure Rating
- UL; V-O flammability rated; type 66 nylon.
- Agency Approvals
- CE; RoHS; cUL; UL.
