PFG2-03 | Process filter gage | range 0-10 psid | green zone 0-5 psid | yellow zone 5-7.5 psid | red zone 7.5-10 psid. | Dwyer
Process filter gage, range 0-10 psid, green zone 0-5 psid, yellow zone 5-7.5 psid, red zone 7.5-10 psid.
Documents and manuals
Dwyer PFG2-03 Documents
Overview
Details for PFG2-03
Process filter gage | range 0-10 psid | green zone 0-5 psid | yellow zone 5-7.5 psid | red zone 7.5-10 psid.
SERIES PFG2 PROCESS FILTER GAGE
The Series PFG2 Process Filter Gage is designed for determining the state of an inline filter. The differential pressure indicator determines the pressure drop on either side of a filter through its 1/8" female NPT pressure connections, and relates the value to one of three zones: clean (green), change (yellow), or dirty (red). The Series PFG2 is perfectly suited for filter applications, line loss, valve drop, and many other differential pressure applications where a simple indicator is needed. The direction of process flow is indicated on the dial, with the arrow pointing to the low pressure port. The PFG2 can be connected in-line through the side process connections, but can also be directly mounted through the outlet/inlet.
Product Applications
- Filter pressure drop
- Filter status
- Valve drop
- Line loss
- Simple easy to understand indicator means no guessing filter status
- Removable mounting block provides direct mounting options especially in difficult filter access locations
- Quick installation reduces time to operation
Specifications
- Series
- PFG2 PROCESS FILTER GAGE
- Category/Type
- Pressure
- Type
- Differential Pressure
- Series
- PFG2 PROCESS FILTER GAGE
- Service
- Liquids/gases compatible with SS; GFN; and fluoropolymer.
- Wetted Materials
- Aluminum; SS; glass filled nylon; and fluoropolymer.
- Accuracy
- ±5% F.S.
- Temperature Limit
- 200°F (93°C).
- Pressure Limit
- 300 psig (20.7 bar).
- Materials
- Body: Glass filled nylon; Mounting Block: Aluminum; Lens: Polyester; Elastomers: Fluoroelastomer.
- Process Connection
- 1/8" female NPT.
- Mounting Orientation
- Any orientation with 10-32 threaded holes 3/4" apart.
- Weight
- 9.6 oz (272.2 g).
